CellLog 8M

CellLog 8M


CellLog 8M


Maintain accurate monitoring and measurement of your battery's voltage with this small but accurate tool.


The simple, easy to use interface on the CellLog's backlit LCD screen lets you view individual cell voltages to a precision of three decimal places.


Note: This meter does not support logging, and has no USB connection. It is meant as a simple voltage checker. For additional features like logging, check out the CellLog 8S here.


Specifications:
  • LiPo/LiIo/LiFe: 2-8 series
  • Pack Voltage Range: 4.0 - 43 V (1.0 V when powered via USB)
  • Alarm Pack Voltage Range: 0.1-4.3V
  • Cell Voltage Range: 1.3-4.9V
  • Alarm Cell Voltage Range: 1.3-4.9V
  • Voltage Display Resolution: 1mV
  • Current Loading of Test: 8mA
  • Maximum Voltage for Alarm Port: 50V
  • Current Drain for Alarm Port: <500mA
  • Weight: 17g
  • Dimensions (LxWxD): 62x39x12 mm

$6.30

Original: $17.99

-65%
CellLog 8M

$17.99

$6.30

Product Information

Shipping & Returns

Description


CellLog 8M


Maintain accurate monitoring and measurement of your battery's voltage with this small but accurate tool.


The simple, easy to use interface on the CellLog's backlit LCD screen lets you view individual cell voltages to a precision of three decimal places.


Note: This meter does not support logging, and has no USB connection. It is meant as a simple voltage checker. For additional features like logging, check out the CellLog 8S here.


Specifications:
  • LiPo/LiIo/LiFe: 2-8 series
  • Pack Voltage Range: 4.0 - 43 V (1.0 V when powered via USB)
  • Alarm Pack Voltage Range: 0.1-4.3V
  • Cell Voltage Range: 1.3-4.9V
  • Alarm Cell Voltage Range: 1.3-4.9V
  • Voltage Display Resolution: 1mV
  • Current Loading of Test: 8mA
  • Maximum Voltage for Alarm Port: 50V
  • Current Drain for Alarm Port: <500mA
  • Weight: 17g
  • Dimensions (LxWxD): 62x39x12 mm
